Factory Outlets Co2 Laser Cutting Machine For Acrylic - VEGA Series-VEGA16 – AEON
Factory Outlets Co2 Laser Cutting Machine For Acrylic - VEGA Series-VEGA16 – AEON Detail:
Overall Review
VEGA16 is a commercial standing model laser engraving and cutting machine. The working area is 1600*1000mm. For VEGA Series of machine, It mainly designed to satisfied those who want to cut certain thickness of flat materials. The machine engraving speed is not so fast as MIRA machines. Although it can go 1000mm/sec, the acceleration speed is 2G. However, this speed is enough to be outstanding over other similar machines on the market. The VEGA Series does not have up and down working table, the worktable is funnel type with drawer underneath to collect the small pieces cut by the machine.
The structure of the machine is very strong, which makes it more steady. The machine equipped with honeycomb and blade worktable and with model3000 or 5000 chiller, makes possible to install 100W or even 150W laser tube. The air assists system got pressure gauge and regulator to give the users option to add more powerful compressor to cut thicker materials. The front and back material pass through door makes it possible to cut long materials.
The machine is also built according to Class I laser standard, with fully enclosed machine body and key lock on every door and window. The lid adopted tempered glass for fire proof purpose.
Overall, the VEGA16 is a very good commercial standing model of laser engraving and cutting machine. It can fit in larger size materials, and could install higher power laser tube to cut thicker materials. It will be an ideal machine for your business and will bring you profit for sure. And with this model, it is a little economic than NOVA16 since it got no up and down working table.
Advantages of the VEGA16
Clean pack Technology
One of the biggest enemy for laser engraving and cutting machine is dust. Smoke and dirty particles will slow down the laser machine and make the outcome bad. The Clean pack design of VEGA16 protects the linear guide rail from dust,reduce maintenance frequency effectively,get much better outcome.
Class 1 Laser Standard
The VEGA16 machine case is fully enclosed. There are key locks on every door and window. The main power switch is key lock type, which prevent the machine from those un-authorized person operating the machine. These features make it much more safe.
Faster than others.
With Customized stepper motor,high quality Taiwan Linear Guide rail and Japanese bearing, the VEGA16 maximum engraving speed is up to 1000mm/sec, acceleration speed is 2G. Faster than other similar machines on the market.
AEON Pro-Smart Software
The Aeon ProSmart software is user friendly and it has perfect operation functions. You can set parameter details and operate it very easy. It will support all file formats as using on market and can direct work inside of CorelDraw, Illustrator and AutoCAD.Most Importantly, the software is Mac Os compatible!
Mufti-Cummunication
The VEGA16 was build with high-speed multi communication system. You can connect to your machine by Wi-Fi, USB cable, LAN network cable and transfer your data by USB Flash disk. Machine has 128 MB memory, LCD screen control panel. With off-line working mode when your electricity down and reboot machine will run on stop position.
Effective Table and front back pass through door
The VEGA got ball screw electric up&down table, steady and precision.Z-Axis height is 200mm, can fit in 200mm height products. The front and back pass through door can fit into the long materials. The funnel worktable with drawer underneath will collect the waste materials or small products very easy and convenient.
Strong and Modern body.
The Case is made up of very thick galvanized steel plate, which is very strong. The painting is powder type, looks much better. The design is much more modern, which fits seamlessly in modern house. The LED illumination inside the machine makes it shinning in the dark room like a super star.
Product detail pictures:
